Hair Brush Drilling and Tufting Machine

Inquire Online

Get the latest price

Quantity Needed：

Pieces

E-mail：

Related Product

PRODUCT DETAILS

Place of Origin:Guangzhou,China

Brand Name:BHF

Model Number:BHF-380A

Product Name:Hair Brush Drilling and Tufting Machine

Condition:New

PAYMENT&SHIPPING

MOQ:1 Set

Price:$2500-$25000

Shipping:By Sea

Port:Guangzhou,China

Packing Detail:Wooden Box

Delivery Time:Around 30 Days

HIGHLIGHTS

(1) Fully automatic,no need to stop the machine even changing the virgin blocks.

(2) Ability to produce HAIR BRUSH with upright tufting,and easy to change design.

(3) Easy to input data,one-hole finishing and suitable for varied designs.

TECHNICAL DATA

Axis	3 Axis
Function	DRILLING and TUFTING
Tufting Mode	Anchor Mode or Staple Mode
Standard Working Area	X-AxisY-AxisZ-Axis =500mm250mm360°
Diameter of Holes(mm)	2-10
Max. Filament(mm)	250
Color of Filament	Single Color or Double Color
Production Speed	240-360/Min.
Material of Brush Block	Plastic,Wooden
Material of Filament	PP,PET,Nylon etc.
Motor	Servo Motor
Quantity of Design	Max. 36000 Hoels
Power Supply	Three Phase 380V
Frequency(HZ)	50-60
Power Consumption(W)	3500
Dimensions of Machine(lwh,mm)	165015001950
Dimensions of Power Box(lwh,mm)	5806601500
Weight(KG)	Around 800
Warranty(Year)	3
